產品描述Product description
◆MK08系列是一款專用型無刷電機控制器(線路板組件)，具有調速，LED燈電量顯示、功能切換等功能，廣泛應用于各類直流無刷充電式手持式電動工具，如：無刷充電扳手、無刷充電電鉆等。
◆MK08 series are one special type Controller (PCB Assembly) for DC brushless motor, integrated with Speed control, LED battery remaining display, function switching, etc. Commonly for used in brushless DC portable power-tools such as DC Brushless Impact Wrench, DC Brushless Drill, etc.
產品特征Features
◆可選帶以下功能 Optional following function types:
→電子調速功能 Electronics Speed Control Function
→LED燈電量顯示 LED battery remaining display
→功能切換 Function switching
技術數據Technical data
→電氣耐久壽命 Electrical life endurance≥3E5
→最大電流 Max. current at 42Vd.c25A
→絕緣電阻 Insulation resistance≥7M Ohm
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端 Input side:
→導線端子 Wire lead terminals
→信號端-專用插座 Single-Socket
◆輸出端 Output side:
→焊接端子 Soldering terminals 6.3×0.8
電氣參數和認證 Electric Rating and Certification
